Sibo занимается потенциометрами и датчиками уже 30 лет.

XL50W
XL50W

XL50W

Draw Wire Sensor

瀏覽量： Вернуться: 2023-01-09

    Характеристики：

  • Incorporate multi-turn contact potentiometer

  • Measurement range: 1000mm

  • Output signal: 5K、10K、0~5V,、0~10V、4~20mA

Измерение


Параметр

General Mechanical Specifications

Measure stroke

1000mm

Protection degree

IP54

Tensile force

2N~4N

Mechanical Life expectancy

1,000,000

Mass

Approx.485g

Housing material

Anodized aluminium alloy

Wirerope

0.6mm flexible wire

Max. reciprocating speed

300mm/s

The length of the cable

2m

Environmental Specifications

Operating temperature range

-30℃～+85℃

Storage temperature range

-30℃～+85℃

Shock

10~1500Hz、10G

Vibration

50G

General Electrical Specifications

Multi-turn wirewound potentiometer model

SAKAE 22HPM

Applied voltage

5V±10%

Output signal

0～5V

Current consumption (no-load)

<30mA

Repeatability accuracy

0.1%

Electrical angle

3600º±5°

Independent linearity tolerance

Standard±0.25% , Precision ±0.15%

Resolution

5000（5K）/ 6400（10K）

Response frequency

≤300KHz

Special Specifications Available

Special specifications

Available for multi-segment output, special cables, high protection degree, etc.
