Protection degree

IP65

Operating torque

≤1mN·m

Max.speed

6000rpm

Shaft load

Radial 60N，Axial 30N

Life expectancy

>2,000,000,000

Mass

Approx.120g

Housing material

Anodized aluminium alloy

Shaft material

Stainless steel

Operating temperature range

-30℃～+85℃

Storage temperature range

-30℃～+85℃

Standard model

EI40NB-F1-W4096-P

Applied voltage

4.75V-30V or 5V for RS-422

Output high level

>VCC-2.5V

Output form

Differential push-pull incremental or RS-422 incremental

Number of output pulse

4096 ppr

Output propagation delay

<5μs

Current consumption (no-load)

≤30mA

Load current

Short-circuit, with A shorted B ≤80mA, Output current -220mA~220mA

Insulation resistance

>1000MΩ (500V.D.C)

Dielectric strength

1 min (500V.A.C)

Special shaft

Special length of shaft、special diameter or special machining on shaft (like shaft slotted、fatted etc.)

Special Output

Differential signal products are available.
